Product Features
Up to 10Gbps bi-directional data links
RJ45 Max 20m
Fully metallic enclosure for low EMI
Compact RJ-45 Connector assembly
Hot-pluggable SFP footprint
Low power dissipation
Extended case temperature: 0℃ to 70℃
RoHS compliant and Lead Free
Applications
√ 10 Gigabit Ethernet
1. Product Description
The RTSFP-10G is Copper Small Form pluggable (SFP) transceiver, which is based
on SFP multi-sourcing agreement (MSA). It is compatible with the 10GBASE-T and
1000BASE-T standards as specified in IEEE Std 802.3.The 1000BASE-T physical
layer IC(PHY) can be accessed via I2C,allowing access to LIMITED PHY settings
and features.
2. Regulatory Compliance
Rollball transceivers are Class 1 Laser Products comply with FDA regulations. Meet
Class 1 eye safety requirements of EN 60825 and the electrical safety requirements of
EN 60950.
